What are the main machine components of a fully automatic potato cassava starch production line

What are the main machine components of a fully automatic potato cassava starch production line

What are the main components of the fully automatic sweet potato, potato, kudzu root, cassava starch production line equipment

1. Conveyor cleaning equipment

Convey raw materials through screw conveyors and belt conveyors, and use blade cleaning machines to clean the raw materials

2. Crushing and crushing equipment

Using a grinding machine or pulverizer to crush raw materials, due to the importance of filing efficiency for starch extraction rate, the filing machine has been specially designed to better crush the raw materials

3. Sludge separation equipment

Use a horizontal or vertical centrifugal sieve to separate the starch slurry and fibers through the action of centrifugal density.

4. Sand removal and starch slurry purification

Use a sand remover to remove sand particles from the crushed material, and use a cyclone to purify, separate, and concentrate the starch slurry to obtain pure starch slurry.

5. Starch dehydration equipment

Dehydrate starch milk using a vacuum dehydrator to achieve a moisture content of approximately 38%.

6. Starch drying and packaging

The wet starch is dried by a low temperature low tower dryer, and the dehydrated starch powder is conveyed to the feed inlet of the airflow dryer through the conveyor belt, and then enters the elevator through the feeder. The heat source of the airflow dryer is a steam heat exchanger. Wet starch is heated by hot air, and the moisture is evaporated. Generally, the dried starch has a moisture content of about 13%. The dried starch is packaged using a packaging machine
